Model 型号	Roller/滚筒		BF	RC	LG	HG
	RD	Capacity 承载 (kg)	Between Frame Width 框架间距离 (mm)	Roller Center 滚筒中心距 (mm)	Conveyor Length 输送机长度 (mm)	Between Frame Width 框架间距离 (mm)
	Roller Diameter 滚筒直径 (mm)
LRC350	35	15	350	75,125,150	3000	700-1000
			450
			550
LRC483	48.3	20	650
			750
			950
LRC600	60	20	1050
			1150
			1250

1)Standard
    Roller --- carbon steel, zinc plated, double spring, precision bearing
    Frame --- carbon steel, powder coated
    Control --- control panel, variable speed controller

2)Optional
    Roller --- stainless, galvanized, rubber coated
    Frame --- stainless, galvanized
    Control --- photo cell controls

Customized Model Available
