| Products >> Joloda Bearing Wheel & Pulley >> SKB series steel wheel |
 |
| |
| Name：Steel skate wheel |
| Model：SKB seies |
|
Information：
Outer race in 1pc.
Racyway carefully hardened.
Zinc plated finish, except stainless model.
Heavy duty capacity. |
|
 |
# | Part No. | Dimension(MM) | Bearing/Ball | Rating | Remark | D | d | E | C | No. | Dia | kg | | SKB387-0601 | 38.7 | 6.5 | 20.6 | 3.8 | 7 | 6.35 | 68 | A5924-R0 | | SKB480-0802 | 48.0 | 8.2 | 24.0 | 4.0 | 8 | 6.35 | 34 | A6218-R0 | | SKB480-0601 | 48.0 | 6.5 | 24.0 | 5.0 | 8 | 6.35 | 34 | A6059-R6 | | SKB480-0801 | 48.0 | 8.2 | 24.0 | 5.0 | 8 | 6.35 | 34 | A6059-R6 |
# | Part No.
品名 | Dimension尺寸(MM) | Ball钢球 | Rating负载 | Remark
说明 | D | d | E | C | No. | Dia | kg | | SKB494-0601 | 49.4 | 6.5 | 20.6 | 2.4 | 7 | 6.35 | 30 | A1611-R2 | | SKB494-0701 | 49.4 | 6.5 | 20.6 | 2.3 | 8 | 6.35 | 36 | A1633-R7 | | SKB494-0702 | 49.4 | 8.1 | 20.6 | 2.3 | 8 | 6.35 | 36 | A1633-R7 | | SKB494-0703 | 49.4 | 8.1 | 24.0 | 4.0 | 8 | 6.35 | 36 | A1633-R7 | | SKB494-0704 | 49.4 | 6.5 | 24.0 | 4.0 | 8 | 6.35 | 36 | A1633-R7 | | SKB494-0705 | 49.4 | 7.3 | 20.6 | 2.3 | 8 | 6.35 | 36 | A1633-R7 | | SKB494-0751 | 49.4 | 6.5 | 20.6 | 2.6 | 7 | 4.76 | 68 | A1933-R0 | | SKB494-1010 | 49.4 | 6.5 | 20.6 | 2.4 | 8 | 6.35 | 50 | A6531-R0 | | SKB494-1020 | 49.4 | 8.1 | 20.6 | 2.4 | 8 | 6.35 | 50 | A6531-R0 | | SKB494-1501 | 49.4 | 6.5 | 20.6 | 2.3 | 8 | 6.35 | 68 | A1546-R8 | | SKB494-1502 | 49.4 | 8.1 | 20.6 | 2.3 | 8 | 6.35 | 68 | A1546-R8 | | SKB494-1503 | 49.4 | 8.1 | 23.8 | 4.0 | 8 | 6.35 | 68 | A1546-R8 | | SKB494-1504 | 49.4 | 6.5 | 41.3 | 23.1 | 8 | 6.35 | 68 | A1546-R8 | | SKB494-1505 | 49.4 | 8.1 | 20.6 | 2.3 | 8 | 6.35 | 68 | A1546-R8 |
# | Part No. | Dimension(MM) | Bearing/Ball | Rating | Remark | D | d | E | C | No. | Dia | kg | | SKB495-0610 | 49.5 | 6.2 | 15.9 | 15.2 | 8 | 6.35 | 45 | A6203-R0 | | SKB495-0620 | 49.5 | 6.2 | 15.9 | 15.5 | 8 | 6.35 | 45 | A6123-R1 |
| # | Part No. | Dimension(MM) | Bearing/Ball | Rating | Remark | | D | d | E | C | No. | Dia | kg | | | SKB575-1610 | 57.5 | 9.5 | 38.6 | 1.9 | FB287-0902S | 160 | A1644-R4 |
# | Part No. | Dimension(MM) | Bearing/Ball | Rating | Remark | D | d | E | C | No. | Dia | kg | | SKB1016-1901 | 101.6 | 19.3 | 31.8 | 4.0 | 12 | 9.53 | 136 | A5450-R5 |
|
|
|
